CHOOSE BETWEEN 946.4-L OR 1135.6-L (250-GAL. OR 300-GAL.) TANK

Choose which tank size best fits the area needing sprayed and the producer’s current tractor.

‍

CHOOSE BETWEEN HYDRAULIC OR POWER TAKE-OFF (PTO) PUMP

The hydraulic 75-204 pump comes standard on the LS1145 model and has a 102.2-L/min (27-gpm) flow. There is also an option to choose a hydraulic 150-206 pump with the LS1145.

The six-roller PTO pump has a 79.5-L (21-gpm) flow and comes standard on the LS1125, LS1130, LS1130BL, and LS1140.

‍

CHOOSE BETWEEN SINGLE NOZZLE BODY OR TRIPLE NOZZLE BODY ON 12.2-M (40-FT) BOOM

Single nozzle bodies come standard on all units. Producers can upgrade to a triple nozzle body for increased accuracy and the ability to quickly change between chemicals.

All models, except the LS1145, fold and unfold manually. Simply remove a pin and swing the arms out, then extend the outermost edge of the boom. The LS1145 hydraulically folds and unfolds, allowing the operator to stay in the cab.

‍

BREAKAWAY BOOMS

The boom has a hinge that allows it to break away instead of damaging crucial components when inadvertently hitting an obstacle.

‍

WET BOOMS

The boom utilizes a stainless-steel pipe, instead of multiple hoses, for product distribution. This configuration leads to fewer parts, less chance of product trapped in the lines, and a reduced pressure drop.

‍

GAS CYLINDER ON MANUAL-FOLD BOOMS

The gas cylinder provides an ergonomic and safe mechanism that shortens manual folding and unfolding time.

‍

RAVEN SCS 450™ CONTROLLER

The Raven SCS 450 Controller automatically controls up to five sections (including two fenceline nozzles) of the boom depending on the speed of the tractor.

NOTE: The Raven SCS 450 option is available on LS1140 and LS1145 models only.

‍

TEXAS INDUSTRIAL REMCOR CONSOLE

The Texas Industrial Remcor console manually controls three separate sections of the boom. It is available in base on all LS11 models.

‍

FOAM MARKERS

Prevent crop damage and inability to control weeds due to skips and overlap by visualizing the placement of chemicals with foam markers.

SCS 450 is a trademark of Raven Industries Incorporated.

The sprayer has an integrated parking stand and fork pockets to make hook up and movement of the sprayer quick and easy. It is Category 2 and 3 quick-hitch compatible.
