Four-point independent suspension delivers a smoother, more comfortable ride. The W155 has four coil-spring shock absorbers working in conjunction with fore-aft and side-to-side stabilizers to minimize cab roll. The shocks are placed at each corner of the cab so the entire cab can go up or down from the resting position. This suspension makes the W155 one of the most comfortable cabs in the industry.

EXCELLENT VISIBILITY TO SEE THE PLATFORM AND CROP DURING FIELD OPERATION

Large, wide-front glass and cab positioned forward and above the platform give excellent visibility to the cutterbar and incoming crop across the widest platforms. This allows ease of operation and maximum productivity even in the toughest cutting conditions.

POWERFUL EXTERIOR LIGHTING MAKES NIGHTTIME OPERATION ALMOST AS EASY AS IN THE DAYTIME

Halogen lighting is used to give the operator excellent visibility when operating at nighttime or in low-visibility conditions.

• Automotive-type lamps use replaceable bulbs for easy service.
• Seven headlights are mounted on the front of the cab to illuminate the cutting area in front of the platform. This gives excellent visibility to the crop and obstacles in the fields.
• Two rear work lights are mounted on the rear of the machine.
• Two adjustable side or rear-facing work lights are mounted on the rear of the cab to illuminate the area to the sides and rear of the machine. This allows seeing stubble and obstacles in the field. The left-hand side light has a delay egress feature.
• When transporting in road range, the flashing hazard lights (and beacon lights if equipped) come on automatically.

An optional HID lighting package (two mirror-mounted HID lights) is available to provide additional lighting. Optional warning beacon lights are available, providing additional visibility during transport.

An optional reverser is available on the W155 only. It is easily activated from the operator's station to clear the platform of plugs that may occur.

On the 400D Platforms, the reverser slowly reverses the knife drive and optional hay conditioner if equipped to clear plugs. The reverser is highly recommended when using the optional hay conditioner with the 400D Draper Platform.

On the 100A Auger Platform the reverser slowly reverses the conditioning rolls, auger, and reel. This makes a difficult job easier, so the operator can be more productive.

Operators can run the machines nearer to their maximum capacity and it will take less time to unplug, adding to the machine productivity.

The reverser consists of a valve block and valves shown in photo above. It is the gold-colored valve block to the right of the photo. It is shown plumbed for a 100A Auger Platform.

Attaching and detaching platforms is easy, allowing fast and narrow draper transport and the ability to quickly change from hay to grain harvest. This allows those with diverse operations to use the machine for more hours annually, spreading out their costs.

A single-point multicoupler on the right-hand side of the machine stores easily out of the way for hay use and is conveniently connected to the platform using the multicoupler.

HYDRAULIC AND ELECTRIC CONNECTIONS ON LEFT SIDE OF MACHINE

The storage position keeps hydraulic and electric connections away from moving components and secure for transport.

Uniquely sized locking flat-face quick-attach couplers provide easy attachment and make connecting virtually fool proof.

A self-latching center-link comes with the optional hydraulic center-link, making connecting the platform easy.

The other optional kit for center-link vertical alignment makes attaching and detaching a breeze for those who move fields frequently or want the ease of attaching. This kit gives the capability to move the center-link up and down with a cylinder under the cab controlled by the reel fore-aft buttons on the multi-function control lever.

PIN ON LOWER LIFT ARMS FOR QUICK-ATTACH

The pin on lower-lift arms allows easy change over from draper to auger platforms and also changing from wide draper in-field operation to narrow transport.

Springs are easily adjustable. Simply raise the platform to relieve spring pressure and turn the bolt to adjust the leverage on the springs. This allows changing platforms quickly and easily.

The float-fine adjust is in base equipment for the W155. It uses a small hydraulic cylinder to adjust spring length and force independently on each side. This also allows changing the platform float for varying field conditions on the go and has three memory positions from which to select. The float-fine adjust also allows rebalancing the platform when using the deck-shift feature by using the same controls on the armrest.

Storing 400D Platform with a W155 is easy with great visibility and control to push the platform in through narrow doorways for off-season storage.
